| Place of Origin: | China |
| Brand Name: | Zhongke |
| Certification: | CE, ISO900 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden pallet or wooden case |
| Delivery Time: | 1month after received 30% deposit |
| Payment Terms: | 30% deposit+70%balance before shipment |
| Tape Width: | ≤19mm | Electrical Power: | 22 Kw |
|---|---|---|---|
| Glue Tank Capacity: | 45L | Air Supply: | 12L/min |
| Net Weight: | 2000kg | Cardboard Pile Height: | 1000 Mm |
| High Light: | automatic pasting machine,box corner pasting machine |
||
Quick Detail:
1. Automatic computer controlled
2. Automatic Failure detection
3. Quick mould switching control device ensures that the length of tape for corner paste can be adjusted.
Description:
Size movement from front and rear, right and left can be moved by a handle. Up and down motion can be operated by pushing a button. Most of the setting tasks can be done in a certain place.
You can make up to 30 PCS per minute.
If cardboard feeding is not done, it will stop automatically. When the cardboard or tape is running out, it tells you by alarm.
You can operate or stop also in the middle of the work by a foot switch.
It can stack a lot of board paper. (If it is Auto lifting type)
Applications:
Jewel box,shoe-box, shirt box, underwear box, gift box, food box, hardware box etc
Specifications:
| Cardboard blank thickness Min | 0.8mm |
| Cardboard blank thickness Max | 3mm |
| Speed | 15-35pcs/min |
| Precision error | ±0.3-0.5mm |
| Cardboard pile height | 1000mm |
| Tape width | ≤19mm |
| Power | 380V50HZ |
| Electrical power | 22kw |
| Glue tank capacity | 45L |
| Air supply | 12L/min |
| Net weight | 2000kg |
| Machine overall dimension | L3*W3*H2.6m |
| Paper wrap size A=width; B=length |
Amin | 80mm |
| Amax | 650mm | |
| Bmin | 155mm | |
| Bmax | 850mm | |
| Box size L=length; W=width; H=height; |
Lmin | 125mm |
| Lmax | 600mm 400mm | |
| Wmin | 50mm | |
| Wmax | 400mm 300mm | |
| Hmin | 15mm | |
| Hmax | 125mm | |
|
Folding Edge Range:R |
Rmin | 80mm |
| Rmax | 650mm |
Competitive Advantage:
Full automatic operation
3. Product general information
| Place of Origin: | China |
| Brand Name: | Zhongke |
| Certification: | CE,ISO900 |
| Model Number: | Zk-6040TJ |
4. Product business terms
| Minimum Order Quantity: | 1 set |
| Price: | |
| Packaging Details: | wooden pallet or wooden case |
| Delivery Time: | 1month after received 30% deposit |
| Payment Terms: | 30% deposit+70%balance before shipment |
| Supply Ability: |
